IC-3PS (3-Piece) Electric Actuated PVC Ball Valves

Pressure Rating

  • 235 PSI at 73°F
  • TEMPERATURE RATING
  • +140°F Maximum PVC
  • +212°F Maximum CPVC
Product Features

Valve Features

  • 2-Way PVC valves
  • 1/2” through 4” size range
  • TFE® seats
  • EPDM, or Viton® body o-rings
  • True union style
  • Threaded or socket weld ends
  • Patented stem design to help prevent leakage in the event of stem damage

Electric Features

  • 120VAC, 220VAC, 24VAC, 12VDC and 24VDC
  • NEMA 4, 4X and 7 housings
  • Manual overrides
  • Visual indicator
  • Open/close or modulating service
Product Chart
VALVE SIZE115 V AC12 V DC230 V AC24 V AC24 V DCNEMA RATING
1/2”IC-3PS-05-100-E-A-4IC-3PS-05-100-E-F-4IC-3PS-05-100-E-H-4IC-3PS-05-100-E-C-4IC-3PS-05-100-E-B-44
3/4”IC-3PS-07-100-E-A-4IC-3PS-07-100-E-F-4IC-3PS-07-100-E-H-4IC-3PS-07-100-E-C-4IC-3PS-07-100-E-B-44
1”IC-3PS-10-100-E-A-4IC-3PS-10-100-E-F-4IC-3PS-10-100-E-H-4IC-3PS-10-100-E-C-4IC-3PS-10-100-E-B-44
1-1/4”IC-3PS-12-100-E-A-4IC-3PS-12-100-E-F-4IC-3PS-12-100-E-H-4IC-3PS-12-100-E-C-4IC-3PS-12-100-E-B-44
1-1/2”IC-3PS-15-100-E-A-4IC-3PS-15-100-E-F-4IC-3PS-15-100-E-H-4IC-3PS-15-100-E-C-4IC-3PS-15-100-E-B-44
2”IC-3PS-20-200-E-A-4IC-3PS-20-200-E-F-4IC-3PS-20-200-E-H-4IC-3PS-20-200-E-C-4IC-3PS-20-200-E-B-44
2-1/2”IC-3PS-25-300-E-A-4IC-3PS-25-300-E-F-4IC-3PS-25-300-E-H-4IC-3PS-25-300-E-C-4IC-3PS-25-300-E-B-44
3”IC-3PS-30-400-E-A-4IC-3PS-30-400-E-F-4IC-3PS-30-400-E-H-4IC-3PS-30-400-E-C-4IC-3PS-30-400-E-B-44
4”IC-3PS-40-675-E-A-4IC-3PS-40-675-E-F-4IC-3PS-40-675-E-H-4IC-3PS-40-675-E-C-4IC-3PS-40-675-E-B-44
1/2”IC-3PS-05-100-E-A-4XIC-3PS-05-100-E-F-4XIC-3PS-05-100-E-H-4XIC-3PS-05-100-E-C-4XIC-3PS-05-100-E-B-4X4X
3/4”IC-3PS-07-100-E-A-4XIC-3PS-07-100-E-F-4XIC-3PS-07-100-E-H-4XIC-3PS-07-100-E-C-4XIC-3PS-07-100-E-B-4X4X
1”IC-3PS-10-100-E-A-4XIC-3PS-10-100-E-F-4XIC-3PS-10-100-E-H-4XIC-3PS-10-100-E-C-4XIC-3PS-10-100-E-B-4X4X
1-1/4”IC-3PS-12-100-E-A-4XIC-3PS-12-100-E-F-4XIC-3PS-12-100-E-H-4XIC-3PS-12-100-E-C-4XIC-3PS-12-100-E-B-4X4X
1-1/2”IC-3PS-15-100-E-A-4XIC-3PS-15-100-E-F-4XIC-3PS-15-100-E-H-4XIC-3PS-15-100-E-C-4XIC-3PS-15-100-E-B-4X4X
2”IC-3PS-20-200-E-A-4XIC-3PS-20-200-E-F-4XIC-3PS-20-200-E-H-4XIC-3PS-20-200-E-C-4XIC-3PS-20-200-E-B-4X4X
2-1/2”IC-3PS-25-300-E-A-4XIC-3PS-25-300-E-F-4XIC-3PS-25-300-E-H-4XIC-3PS-25-300-E-C-4XIC-3PS-25-300-E-B-4X4X
3”IC-3PS-30-400-E-A-4XIC-3PS-30-400-E-F-4XIC-3PS-30-400-E-H-4XIC-3PS-30-400-E-C-4XIC-3PS-30-400-E-B-4X4X
4”IC-3PS-40-675-E-A-4XIC-3PS-40-675-E-F-4XIC-3PS-40-675-E-H-4XIC-3PS-40-675-E-C-4XIC-3PS-40-675-E-B-4X4X
1/2”IC-3PS-05-100-E-A-7IC-3PS-05-100-E-F-7IC-3PS-05-100-E-H-7IC-3PS-05-100-E-C-7IC-3PS-05-100-E-B-77
3/4”IC-3PS-07-100-E-A-7IC-3PS-07-100-E-F-7IC-3PS-07-100-E-H-7IC-3PS-07-100-E-C-7IC-3PS-07-100-E-B-77
1”IC-3PS-10-100-E-A-7IC-3PS-10-100-E-F-7IC-3PS-10-100-E-H-7IC-3PS-10-100-E-C-7IC-3PS-10-100-E-B-77
1-1/4”IC-3PS-12-100-E-A-7IC-3PS-12-100-E-F-7IC-3PS-12-100-E-H-7IC-3PS-12-100-E-C-7IC-3PS-12-100-E-B-77
1-1/2”IC-3PS-15-100-E-A-7IC-3PS-15-100-E-F-7IC-3PS-15-100-E-H-7IC-3PS-15-100-E-C-7IC-3PS-15-100-E-B-77
2”IC-3PS-20-200-E-A-7IC-3PS-20-200-E-F-7IC-3PS-20-200-E-H-7IC-3PS-20-200-E-C-7IC-3PS-20-200-E-B-77
2-1/2”IC-3PS-25-300-E-A-7IC-3PS-25-300-E-F-7IC-3PS-25-300-E-H-7IC-3PS-25-300-E-C-7IC-3PS-25-300-E-B-77
3”IC-3PS-30-400-E-A-7IC-3PS-30-400-E-F-7IC-3PS-30-400-E-H-7IC-3PS-30-400-E-C-7IC-3PS-30-400-E-B-77
4”IC-3PS-40-675-E-A-7IC-3PS-40-675-E-F-7IC-3PS-40-675-E-H-7IC-3PS-40-675-E-C-7IC-3PS-40-675-E-B-77
