Stainless Steel Ball Valve Drop-Down Line Kit

The Strahman M-120 Drop-Down Line Kit brings together the essential components needed for dependable point-of-use cleaning in one convenient package. Designed for facilities with a dedicated hot or cold water supply, the kit combines the compact, wall-mounted M-120 stainless steel washdown station with a flexible extruded hose assembly and an ergonomic Hydro-Pro 150® spray nozzle with swivel.

By specifying the station, hose, and nozzle as one complete kit, facilities can simplify equipment selection and provide operators with a coordinated washdown system ready for demanding daily use. The M-120 Drop-Down Line Kit delivers straightforward single-valve water control, while the stainless steel hose rack keeps the hose organized and accessible between cleaning tasks. The lightweight hose provides the flexibility needed to maneuver around equipment and work areas.

Product Features

• M-120 single hose station is designed for hot (red handle) or cold water (blue handle)
• Compact and easy-to-use point-of-use cleaning solution for industrial environments
• Available with Black Hose and Black Nozzle, Yellow Hose and Black Nozzle, or White Hose and White Nozzle
• Hose is lightweight and flexible
• Hose outer cover provides superior resistance to degradation and abrasion, as well as resistance to lactic acid and oil
• Non-potable water only
• Standard hose lengths of 25′, 50′, 75′, and 100′–custom lengths available up to 100′
• Hydro-Pro 150®
  • Patented locking trigger mechanism with a safety lock to prevent accidental sprays
  • Stainless steel seat design prevents leakage
  • Stay-cool technology even when hot water (up to 200ºF) is in use
  • Ergonomic design: Swivel-Pro adapter combined with the spray nozzle’s lightweight design (under 2 lbs) minimizes operator fatigue

Inputs and Outputs

• Maximum Water Pressure: 150 psi
• Hose Maximum Water Pressure: 300 psi
• Temperature range: -22°F (-30°C) to 200°F (93°C)
• Output: 3-1/4 to 9 GPM for pressure ranges from 20 psi to 100 psi

Specifications

• Valve
  • Material: Stainless Steel
  • Stainless Steel Hose Rack
  • Mounting Hardware Included
• Hose
  • Material: NBR
  • Reinforced with polyester fabric, 1 braid
  • Fittings: Stainless steel 3/4″ NPT on unit end
  • FDA-Compliant: Safe for food contact
  • FDA CFR Title 211, item 177.2600 standards for fatty foods
  • IANESCO certificate nr. 10/11358 for milk and yogurt
• Hydro-Pro 150® Nozzle
• Swivel-Pro Adapter

NOTE: The image above is representative of the products in this series, and while we try to be as accurate as possible, the product you receive may differ slightly depending on your selection. Please refer to data sheets and technical drawings for dimensions.
